SHIFT TV Upute za prijenos uživo · RTMP Live streaming instructions · RTMP

Onboard uživo
na SHIFT TV

Onboard live
on SHIFT TV

S telefona, GoPro ili DJI kamere. Ne treba ti nikakvo tehničko znanje — upiši svoj startni broj, kopiraj link i slijedi korake za svoj uređaj.

From a phone, a GoPro or a DJI camera. No technical knowledge needed — enter your start number, copy the link and follow the steps for your device.

UređajDeviceTelefon, GoPro HERO7+, DJI Osmo Action 3+ / Pocket 3Phone, GoPro HERO7+, DJI Osmo Action 3+ / Pocket 3
InternetInternetWi-Fi ili dobar 4G/5G, minimalno ~5 Mbps uploadWi-Fi or a good 4G/5G signal, at least ~5 Mbps upload
AplikacijaAppLarix, GoPro Quik ili DJI Mimo — sve besplatnoLarix, GoPro Quik or DJI Mimo — all free
Podaci serveraServer detailsUpisuješ jednom, koristiš svaki putEnter once, use every time
02

Provjeri prije utrke

Check before the race

Pusti prijenos 2–3 minute i pogledaj ga na računalu u VLC playeru. Tako znaš da slika stvarno stiže na server.

Run the stream for 2–3 minutes and watch it on a PC in VLC. That way you know the picture really reaches the server.

  1. Pokreni prijenos na uređajuStart the stream on your device Slijedi korake za svoj uređaj niže na stranici. Follow the steps for your device further down this page.
  2. Otvori VLC na računaluOpen VLC on a PC Izbornik Media → Open Network Stream ili tipke CTRL + N. Menu Media → Open Network Stream or press CTRL + N.
  3. Zalijepi cijeli link i klikni PlayPaste the full link and click Play Ako prijenos radi, slika se pojavi za nekoliko sekundi. If the stream is running, the picture appears after a few seconds.
03

Odaberi svoj uređaj

Pick your device

Koraci, aplikacija i video upute za svaki uređaj.

Steps, app and video guides for each device.

Larix Broadcaster
Besplatno · Android i iPhoneFree · Android and iPhone
Google Play App Store / iOS Upute proizvođačaMaker's docs
  1. Instaliraj aplikacijuInstall the app Potraži Larix Broadcaster u trgovini. Kod prvog pokretanja dopusti pristup kameri i mikrofonu. Search the store for Larix Broadcaster. On first launch, allow access to the camera and the microphone.
  2. Otvori postavke vezeOpen the connection settings Dodirni zupčanik gore, pa Connections. Tap the gear icon at the top, then Connections.
  3. Dodaj novu vezuAdd a new connection Dodirni + gore desno → New connection. Pod Name upiši npr. SHIFT TV. Tap + at the top right → New connection. Under Name enter e.g. SHIFT TV.
  4. Upiši linkEnter the link U polje URL zalijepi cijeli link iz koraka 01. Ostalo ne diraj i dodirni Save. Paste the full link from step 01 into the URL field. Leave the rest as it is and tap Save.
  5. Namjesti kvalitetuSet the quality Natrag → Settings › Video. Preporuka: 1080p, 30 fps, bitrate 4–6 Mbps. Na slabijoj mreži 720p. Go back → Settings › Video. Recommended: 1080p, 30 fps, bitrate 4–6 Mbps. On a weaker network use 720p.
  6. Okreni telefon vodoravnoTurn the phone sideways Na glavnom ekranu možeš prebaciti prednju i stražnju kameru. Telefon drži vodoravno (landscape). On the main screen you can switch between the front and rear camera. Hold the phone horizontally (landscape).
  7. Kreni uživoGo live Pritisni veliki crveni gumb. Kad postane zelen ili piše Connected, ideš uživo. Za kraj pritisni isti gumb. Press the big red button. When it turns green or shows Connected, you are live. To finish, press the same button again.

Video uputeVideo guides

Setting SRT, RTMP and RTSP connections in Larix Broadcaster Softvelum — proizvođač aplikacije. Ovo je točno postupak iz koraka 2–4. Softvelum — the app maker. This is exactly the steps 2–4 procedure.
How to live stream using Larix Broadcaster mobile app Od instalacije do prijenosa uživo, korak po korak. From install to going live, step by step.
04

Koju kvalitetu odabrati

Which quality to choose

Stabilan 720p je bolji od 1080p koji zapinje.

A stable 720p beats a stuttering 1080p.

RazlučivostResolution Bitrate KadaWhen
1080p4–6 MbpsDobar Wi-FiGood Wi-Fi
720p2,5–4 MbpsProsječna mreža — najsigurniji izborAverage network — the safest choice
480p1–1,5 MbpsU pokretu ili slab signalOn the move or weak signal
Audio128 kbps · 48 kHz
FPS25 ili 30 sličica u sekundi je dovoljno25 or 30 frames per second is enough
05

U autu

In the car

Karoserija auta je metalna kutija i guši mobilni signal. Ova tri pravila rješavaju najveći dio problema s onboard prijenosom.

A car body is a metal box and it blocks the mobile signal. These three rules solve most onboard streaming problems.

Telefon što bliže vjetrobranuPhone as close to the windscreen as possible Staklo propušta signal, lim ne. Uređaj drži uz vjetrobran ili bočno staklo — nikad u pretincu, ispod sjedala, u torbi ili u prtljažniku. Glass lets the signal through, sheet metal does not. Keep the device against the windscreen or a side window — never in the glovebox, under a seat, in a bag or in the boot.
Ako slika stane — ne diraj ništaIf the picture drops — don't touch anything Na dijelovima staze bez signala prijenos će stati. Sustav se sam ponovno spaja čim signal ojača. Ne gasi i ne pokreći aplikaciju ponovno tijekom vožnje. On parts of the track without coverage the stream will drop. The system reconnects on its own as soon as the signal returns. Do not close or restart the app while driving.
Nakon utrke prekini vezuAfter the race, stop the connection Zaustavi prijenos i ugasi kameru čim završiš vožnju. Uređaj koji ostane spojen nastavlja slati i isprazni bateriju do kraja. Stop the stream and switch the camera off as soon as your run is over. A device left connected keeps sending and will drain the battery flat.
06

Zlatna pravila

Golden rules

Pročitaj prije prvog prijenosa — ušteda živaca.

Read this before your first stream — it saves a lot of nerves.

Wi-Fi ispred mobilne mrežeWi-Fi over mobileWi-Fi je stabilniji. Na otvorenom traži mjesto s dobrim 4G/5G signalom.Wi-Fi is more stable. Outdoors, find a spot with a good 4G/5G signal.
Napuni baterijuCharge the batteryPrijenos i Wi-Fi brzo troše bateriju. Ponesi rezervnu ili powerbank.Streaming and Wi-Fi drain power fast. Bring a spare battery or a power bank.
Testiraj 2–3 minuteTest for 2–3 minutesPrije pravog prijenosa, ne u zadnji čas.Before the real stream, not at the last minute.
Drži uređaj vodoravnoHold the device sidewaysLandscape, osim ako se ne dogovorimo drugačije.Landscape, unless agreed otherwise.
Ne zaključavaj telefonDon't lock the phoneI ne zatvaraj aplikaciju dok prijenos traje.And don't close the app while the stream is running.
Ako slika zapinjeIf the picture stuttersSpusti razlučivost ili bitrate. Bolje niže i stabilno.Lower the resolution or the bitrate. Lower and stable is better.
07

Ako nešto ne radi

If something does not work

Otvori problem koji ti se javio.

Open the problem you ran into.

Ne spaja se · „Connection failed”It will not connect · "Connection failed"
Provjeri je li link kopiran točno — bez razmaka na kraju. Provjeri radi li internet na uređaju. Ako i dalje ne ide, javi se da provjerimo je li server upaljen i port otvoren.Check that the link is copied exactly, with no space at the end. Check that the internet works on the device. If it still fails, get in touch so we can check that the server is on and the port is open.
Slika zapinje ili kasniThe picture stutters or lags
Spusti bitrate ili razlučivost za jedan stupanj. Priđi bliže Wi-Fi ruteru ili nađi mjesto s jačim signalom.Lower the bitrate or resolution one step. Move closer to the Wi-Fi router or find a spot with a stronger signal.
Nema zvukaNo audio
Provjeri je li mikrofon isključen u aplikaciji i ima li aplikacija dopuštenje za pristup mikrofonu u postavkama telefona.Check that the microphone is not muted and that the app has permission to access the microphone in the phone settings.
Prijenos stane nakon par minutaThe stream stops after a few minutes
U autu je to najčešće dio staze bez pokrivenosti — prijenos se sam vrati kad signal ojača, ne diraj ništa. Ako stane i ne vrati se, provjeri bateriju i isključi štednju baterije za tu aplikaciju u postavkama telefona.In a car this is usually a stretch of track with no coverage — the stream comes back on its own when the signal returns, so don't touch anything. If it stops and does not return, check the battery and turn off battery saving for that app in the phone settings.
Kamera ne nudi RTMPThe camera does not offer RTMP
Ažuriraj firmware kamere i aplikaciju, pa provjeri je li tvoj model podržan. GoPro od HERO7 naviše, DJI Osmo Action 3 naviše i Osmo Pocket 3.Update the camera firmware and the app, then check whether your model is supported. GoPro from HERO7 up, DJI Osmo Action 3 up and Osmo Pocket 3.
Slika je okrenuta ili uspravnaThe picture is rotated or vertical
Okreni uređaj vodoravno prije nego pokreneš prijenos, ne tijekom.Turn the device horizontally before starting the stream, not during it.
